SDI to USB 3.0 Video Capture Card 1080P 60 FHD E261441
SDI to USB 3.0 Video Capture Card 1080P 60 FHD E261441
1080P60 FHD SDI Input
YUV 4:2:2 BT.709 Color Space
High Speed USB3.0 Interface
Support Win7/8/10,Mac,Linux,Andriod
Free Driver and Compatible OBS/Vmix/Wirecast/Xsplit/VLC/Potplayer etc.
Interface
USB interface: USB3.0，360MB/s Bandwidth(Compatiable USB2.0)
Input interface: 1xSDI,
Output interface: N/A
Video input: 1080P50/60,1080I50/60,720P50/60,576P,576I,480P,480I
Audio input: SDI embedded
System: Windows (7, 8, 8.1,10), Linux (kernel version 2.6.38 and above), OS X (10.8 and above)
Standard
HDMI input format: SD/HD/3G-SDI，SMPTE-259/274/296/372/424/425/292 compliance
Transmission speed: SDI:1.485Gb/s，2.97Gb/
Video capture: UVC (USB video class) compliance
Audio capture: UAC (USB audio class) compliance
Output color space: YUY2
General
Operation system: Support version x86 & x64 from Windows 7、8.1、10，Windows Server 2008 R2
Compatible software: Windows Media Encoder, ,Adobe Flash Media Live Encoder, Real Producer Plus, VLC, Wire cast, AMCAP etc.…
Compatible development interface: DirectShow (Windows), DirectSound (Windows)
Update: Firmware can be updated by USB port
Dimension: 70x100x24mm
